Powerlink Microgrid Residential Solution

thumbnail-image

CHE500 : 500 kW Output

System Output Power	kWe 500
Battery capacity	kWh 1040
Cooling Method	Liquid Cooled
CHAG./Dischar. Rate	0.5C
Noise level	dBA@7m 58
Dimensions	mm 4150×2200×2510
Dry weight	kg 13506

Powerlink CHE 500 commercial battery delivers 1040 kWh capacity, ensuring reliable energy storage for Australia.

The Powerlink CHE500 is a high-performance commercial energy storage system designed for large-scale and industrial energy needs. Delivering 500 kW of output power and equipped with a 1,040 kWh battery capacity, it supports a 0.5C charge/discharge rate for consistent and efficient energy delivery. Featuring advanced liquid cooling for optimal thermal management and operating quietly at 58 dBA @ 7m, the CHE500 ensures reliability and long-term performance. With a sturdy design and a dry weight of 7,860 kg, it is the ideal solution for demanding applications requiring reliable backup, load balancing, and energy independence.

CHE500 Features:

CHE500 Commercial Battery Storage Applications

The CHE commercial battery storage system suits businesses that need reliable energy control and cost management. It supports offices, retail centres, warehouses, manufacturing sites, and mixed commercial facilities. The system helps manage peak demand, store excess solar energy, and improve power reliability with minimal operational effort.

C and I Facilities
CHE battery storage helps commercial and industrial users manage peak demand, reduce energy cost, and improve power stability in high load environments.

Manufacturing Plants
The system supports machinery start up loads, smooths power fluctuations, and helps maintain consistent production without stressing the grid connection.

Shopping and Commercial Industry
CHE battery storage reduces peak demand charges in shopping centres and commercial buildings while supporting solar self use during trading hours.

Refrigerated Logistics
Battery storage supports cold storage and refrigerated warehouses by improving power reliability and reducing the risk of temperature deviation during grid instability.

Hospitals and Healthcare Facilities
CHE systems support critical loads, improve power resilience, and help facilities manage energy use while maintaining continuity of care.

Why Chose CHE500 Commercial Battery

Clients rely on PowerLink commercial battery storage because it delivers practical benefits that matter in daily operations. The systems focus on energy control, reliability, and long term cost reduction rather than theory. Local support from PowerLink Australia helps businesses adopt battery storage with confidence.

Proven Battery Technology
PowerLink uses tested battery cells and power electronics that deliver stable performance and long service life in commercial environments.

Energy Cost Control
Battery storage helps reduce peak demand charges, improve solar self use, and manage energy costs during high tariff periods.

Reliable Power Support
The system supports critical loads and improves power continuity during grid instability or short outages.

Scalable Capacity Options
PowerLink commercial battery storage is available in flexible capacity ranges that can grow with business demand.

Australian Compliance
Systems are designed to meet Australian electrical and safety standards for commercial and industrial use.

Local Warranty and Support
PowerLink Australia provides warranty coverage, spare parts, and service partners to support long term system operation.

FAQs

What are the power output capacities of the CHE125, CHE250, and CHE500?

The CHE125 offers 125 kW continuous and 150 kW maximum output. The CHE250 provides 250 kW continuous and 300 kW maximum. The CHE500 delivers 500 kW continuous and 600 kW maximum.

What voltage options are available across the CHE range?

All models (CHE125, CHE250, CHE500) support three-phase AC voltages of 380 V, 400 V, and 415 V, ensuring flexibility for various grid requirements.

What components are integrated inside the CHE units?

Each CHE unit integrates a PCS (power conversion system), battery, BMS (battery management system), MPPT (solar controller), and EMS (energy management system) into one compact solution.

Can the CHE units operate both on-grid and off-grid?

Yes, the CHE systems support both grid-connected and off-grid operation modes for flexible use in different energy scenarios.

How to Measure the Power Requirement for My Load?

To measure the power requirement for your load, list all the electrical appliances or systems that will be powered by the generator. Calculate the total wattage by adding the individual wattages of these appliances or systems. This sum gives you an estimate of the power requirement. Ensure to consider both starting and running wattage for accurate assessment.
